F1 set for pitstop tweak to combat unsafe releases

An unsafe release from McLaren in practice for the Chinese Grand Prix was the fifth such problem in three grand prix weekends and came a week after a Ferrari pit crew member suffered a broken leg in Bahrain.

The unsafe releases have occurred despite all 10 teams employing a semi-automated system that is supposed to stop drivers being given the green light to leave their pit box before the pitstop is complete.

FIA race director Charlie Whiting has revealed he has a possible solution he will present to teams in the coming weeks.

“I think we can introduce a few things to improve, to decrease the likelihood of mistakes, yes,” Whiting said when asked by Motorsport.com if there were still concerns about the pitstop procedures after an incident-free Chinese Grand Prix.

“I think we have learned something. We need to again analyse things to ensure that what we do, we do it precisely to make sure everyone is able to follow that.”

Automated elements in F1 pitstops have advanced to include wheelgun sensors that help the gun operator signal when their wheel change is complete.

When this process is complete on all four wheels, the driver is shown the green light.

A confused sensor measuring the tightness of the wheel nut was to blame for Ferrari’s early release of Kimi Raikkonen in Bahrain that broke Francesco Cigarini’s left leg.

Neither the rear jack operator or pitstop controller, who could have overridden the system, saw the rear-left had not actually been changed and Whiting wants to beef up the process so there are more parameters for the automated part of the system to satisfy.

This is likely to be mandating all teams utilise two wheelgun sensors: one to ensure the right torque has been applied to tighten the nut, and one to check its position in case it has been cross-threated by mistake.

The likes of Haas, which lost a big Australian GP result thanks to two unsafe releases, and McLaren do not utilise dual sensors and released their cars with cross-threaded nuts.

“So, you’re using two sensors to tell the operator it’s actually done up, he presses a button, both jacks drop and the car goes,” said Whiting.

Renault chief technical officer Bob Bell suggested in China that the FIA could standardise the automated system as part of its 2021 rules package to gain greater control over safety.

Whiting said individual systems were fine as long it is not possible for a gun operator to declare their wheel is secured without being completely sure.

“I don’t think we need to standardise it,” he said. “We need to make sure that among other things there is no possibility for the guy to give the OK until those two conditions have been met.”
