Ford Cosworth ED specifications

Ford Cosworth ED

Configuration                   75 degree V8
Capacity                        2995cc
Maximum RPM                     13,500 rpm
Weight (dry)                    129.5 kgs
Length                          595 mm / 23.4 ins
Height                          542 mm / 21.3 ins, inc Air filter
Crankcase/Cylinder heads        Aluminium Alloy
Engine management               Cosworth Electronic
Ignition                        Electronic CD
Bore-stroke                     Confidential to Cosworth
Compression                     Confidential to Cosworth
Maximum power                   Confidential to Cosworth

- The Ford Cosworth ED combines new technology with proven features from previous Formula One engines to produce a powerful yet reliable engine and platform for future development.

- Major engine casting utilise Cosworth's unique casting process resulting in high strength thin section components. - The engine features pneumatically operated valves and lightweight valve train components. - Lightweight piston design, produced in Cosworth's own piston facility.

- An integral lower airbox and air filter assembly is included.

- Electrical systems are terminated on engine, and improved connections for cooling and lubrication systems allow for easier installation and permit variations in chassis design. - Advanced materials are used throughout the engine to reduce friction and internal losses.
